Ricoma CHT2 Tubular Embroidery Machine

• This CHT2 series embroidery machine is best design for large scale production for apparel & garment manufacturing industry to embroidery work on all kind of readymade garment products and cap products. Fully Automatic and user friendly features make this machine more unique for apperal and garment manufacturing industry.

Machine Features-

• Double beam design to reinforce machine stability and reduce vibration

• Double belt system allows for higher torque, less noise and easier maintenance

• Reinforced square guide rails allow for higher impact resistance and durability

• Leveling feet pre-mounted in the factory for easy transportation and installation

• Double lighting system for better visibility

• Suitable for embroidery on flats, caps, finished garments and more

• Perfect for established and growing embroidery businesses

• 10.4-inch HD LCD touch-screen panel

• Maximum embroidery area: 400mm x 450mm [16” x 18”]

• Optional wide model with embroidery area of 500 mm x 450 mm [20” x 18”]

• Newly developed small sewing arm for high-quality embroidery on caps and small items

• Heavy duty steel stand with wheels to ensure stability and mobility

• Maximum speed: 1,000 stitches per minute

• Memory capacity: 70 million stitches or 200 designs

• 270° wide angle cap system

• Environmentally friendly packaging

• USB input for design transfer.

• Servo motor 150 W – lowest power consumption in the industry!

• Built-in universal power supply 110V/60Hz and 200V/50Hz (self adaptable worldwide)

• DC36V micro-step motor for X & Y axis driving to ensure low noise and less vibration

• Emergency stop button

• Automatic thread trimmer

• Thread break detection

• Easily apply appliqué, sequin, boring or cording

• Recessed USB port to protect USB flash drive

• Machine reads multiple design formats, such as DST, DSB and more

• New embroidery frame positioning board makes changing embroidery frames easier

• Slim machine width allows for easy entry through standard sized doors

• Multiple hoop sizes for a variety of embroidery needs

• Automatic memory retention

• Optional laser tracing device available

Technical Specification-

• Machine Name: CHT2 / CHS2 Series

• Model: Available up to 12heads

• Brand: Ricoma

• Panel: High-Definition True-Color 10.4” LCD Touch Screen

• Heads: 2 - 12heads

• Needles: 12/15

• Net Weight: 650kg - 1500kg

• Embroidery Area: 400 x 450mm (Optional: 450 x 500mm)

• Cap Embroidery Area: 270°

• Maximum Speed 1000 spm

• Voltage: 90-240 v

• Power Consumption: 0.5kw - 1.5kw
