Computerized Embroidery & Quilting Machine

• This quilting & embroidery machine is specially designed for home textile industry, it can be do quilting & embroidery work at the same time of working. Equipped with latest & advance features making quality products and can be use fabric and artificial rexene for making wide range of home textile products.

Machine Features -

• Adopted Japanese Technology.

• X-Y driven by servo motor, main motor spindle clutch motor.

• Automatic color change, arbitrary head for quilting and embroidery.

• Continuous quilting of independent pattern, skipping quilting function unlimited and continuous quilting and embroidery in Y direction, front and rear automatic tensioning systems.

• Support USB disk and readable Tajima, Barudan, ZKS, SWF embroidery format.

• Independent presser foot operation to make the product have three-dimensional aesthetics rolling shaft design in Y direction, cloth can be continuously sewn or quilted Simple, convenient and feasible operation.

• Automatic thread break detects, even at high speed so no need to look around on machine.

• Hard drive and software protection if sudden power cut.

• Self-speed adjusts on running time.

• Speed Down to 200rpm and up to 850rpm/min.

• Mechanical and computer systems are designed user-friendly so there is no special requirement, and it is very easy to operate.

Technical specification:-

• Max Speed: 850rpm

• Stitch Length: 0.8 ~ 12.7mm

• Store Pattern in Computer: 50EA

• Rotary Hook: Japan

• Power: 5.0kw

• Rated Power: 380VAC, 3Phase, 50/60Hz.

• Weight: 4000kg

• Dimension (L*W*H): 5150* 1860* 1450mm
